EDP-S Elevator
About the product
The EDP-S Pneumatic Elevator features manual locking with the option of manual operation. It is designed for gripping and supporting drill pipe and casing strings during running and pulling operations in oil and gas well drilling
- Diameter
- 60-89
- Rated Load
- 80-100
Technical specifications
| Parameter | EDP-S-80 | EDP-S-100 |
|---|---|---|
| Maximum Load Capacity, t | 80 | 100 |
| Nominal Pipe Diameter, mm | 60; 60B; 73; 73B; 89; 89B; 89V; 89N | 89 |
| Pipe Bore Diameter, mm | 62; 68; 75; 82; 85; 91; 97.5; 100; 105 | 92/92 |
| Overall Dimensions, mm | 430×430×230 | 440×420×235 |
| Complete Assembly Weight, kg | 50 | 68 |
Description
The elevators are designed for operation in temperate and cold macroclimatic regions (Regions I1 and I2) in accordance with GOST 16350.
Climate version U is intended for ambient temperatures ranging from −50°C to +45°C. Climate version HL is intended for ambient temperatures ranging from −60°C to +45°C.
The product is classified as Category 1 in accordance with GOST 15150.
Load-bearing components, including the body, slips, door, and accessories, are manufactured from cast alloy steel containing chromium, nickel, and molybdenum, and are subjected to heat treatment to ensure high strength and durability.
The design and manufacture of the elevators comply with API Specifications 8A and 8C.
