Spider SPG-140
About the product
The SPG-140 Spider is designed for gripping tubing and drill pipes with outer diameters of 60 mm (2 3/8"), 73 mm (2 7/8"), 89 mm (3 1/2"), 102 mm (4"), 114 mm (4 1/2"), and 146 mm, and for suspending them at the wellhead during running and pulling operations in oil well drilling and workover applications
- Diameter
- 60-146
- Load
- 140
Technical specifications
| Parameter | Value |
|---|---|
| Rated Load Capacity, kN (t) | 1400 (140) |
| Pipe Diameters, mm | 48, 60, 73, 89, 102, 114, 121, 127, 140, 146 |
| Slip Actuation Drive | Hydraulic or pneumatic |
|
Working Pressure, MPa from hydraulic system from pneumatic system |
3–5 0.6–0.9 |
|
Ambient Temperature, °C operating maximum operating |
–40 to +40 –50 to +45 |
| Overall Dimensions, mm | 585×645×445 |
| Weight, kg | 230 |
