ShBD Drilling Bails

About the product

TU 05273837.303838.040

The SHBD Double-Strand Drilling Links are designed for suspending elevators from the hooks of the hoisting systems (for elevators and hooks with a length of no more than 1800 mm) during running and pulling operations in oil and gas well drilling

Length: 900-2400

Load Capacity: 80-320

All specifications

Technical specifications

Code	Leg Diameter, mm	Load Capacity, t	Length, mm	Width, mm	Weight, kg
SHBD-80-900	65	80	900	485	110
SHBD-80-1200	65	80	1200	485	140
SHBD-80-1600	65	80	1600	485	180
SHBD-125-1100	75	125	1100	520	170
SHBD-125-1800	75	125	1800	520	270
SHBD-200-1800	85	200	1800	570	350
SHBD-200-2100	85	200	2100	570	400
SHBD-320-2400	90	320	2400	590	465

Description

SHBD double-leg drilling links are designed for suspending elevators from the hooks of traveling block systems (with elevator and hook seating lengths not exceeding 1800 mm) during tripping operations in oil and gas well drilling. Custom lengths and seating radii are available upon request.
