LV-01V Auxiliary Winch
About the product
The LV-01V Auxiliary Winch is designed for transporting loads and tools from receiving bridges to the drilling site, lifting loads, and making up and breaking out casing pipes
Technical specifications
| Parameter | Value |
|---|---|
| Pulling force, kg | 3000 |
| Wire rope diameter, mm | 14 |
| Winch drum diameter, mm | 380 |
| Four-layer rope capacity, m | 85 |
| Rope winding/unwinding speed, m/s | 0–0.4 |
| Hydraulic motor operating pressure, MPa | 10 |
Description
The LV-01V auxiliary winch is designed for transporting loads and tools from pipe racks to the drilling floor, lifting loads, and making up and breaking out casing pipes.
The LV-01V auxiliary winch is supplied complete with:
- 310.3.112 or 310.3.56 hydraulic motor;
- pressure roller to ensure proper wire rope spooling onto the drum.
