LG-35 Auxiliary Winch
About the product
The LG-35 Auxiliary Winch is designed for transporting loads and tools from receiving bridges to the drilling site and lifting loads
Technical specifications
| Parameter | Value |
|---|---|
| Pulling force, kN | 35–40 |
| Gearbox reduction ratio | 29.9 |
| Wire rope diameter, mm | 14–16.5 |
| Winch drum diameter, mm | 380 |
| Three-layer rope capacity, m | 100 |
| Rope winding/unwinding speed, m/s | 60 |
| Winch weight without rope, kg | 330 |
Description
The LG-35 auxiliary winch is designed for transporting loads and tools from pipe racks to the drilling floor, lifting loads, and making up and breaking out casing pipes.
The LG-35 auxiliary winch is supplied complete with:
- 310.3.112 or 310.3.56 hydraulic motor;
- pressure roller to ensure proper wire rope spooling onto the drum.
