KMTO Lightweight Power Pipe Tong
About the product
It is designed for final make-up and break-out of threaded connections on drill pipe and tubing during running and pulling operations in oil and gas well drilling and workover applications
- Diameter
- 60-114
- Force
- 900
- Torque
- 600
Technical specifications
| Parameter | Value |
|---|---|
| Maximum torque, kN·m (kgf·m) | 5.9 (600) |
| Permissible force at the end of the lever, kN (kgf), max. | 8.8 (900) |
| Nominal diameters of make-up and break-out pipes (tool joints), mm | 60, 73, 89, 102, 114 |
| Weight, kg | 34 |
| Overall dimensions, mm | 800×740×230 |
| Mean time between failures (MTBF), h | 600 |
| Total service life, years, min. | 4 |
* Jaws: standard supply set
Description
Designed for final make-up and break-out of threaded connections of drill pipes and tubing during tripping operations in drilling and well workover.
