KMBO-135 Power Drill Tong
About the product
The KMBO-135 Power Drill Tong is designed for final make-up and break-out of threaded connections on drill pipe, heavyweight drill pipe, and casing during running and pulling operations in oil and gas well drilling
- Diameter
- 60-508
- Force
- 8000
- Torque
- 13766
Technical specifications
| Parameter | Value |
|---|---|
| Maximum Torque, kN·m (kgf·m) | 135 (13,766) |
| Permissible Force Applied at the End of the Lever, kN (kgf) | 80.3 (8,000) |
| Nominal Diameter of Pipe (Tool Joint) Connections for Make-up and Break-out, mm |
73–114, 102–299, 324–351, 340–432, 426–451, 473–533 |
| Overall Dimensions, mm, max. | 1600×750×1090 |
|
Weight, kg — assembled with 60–102 jaw, without suspension — assembled with 60–102 jaw, with suspension — with complete set of interchangeable parts and suspension |
177 190 350 |
| Standard Supply Package |
KMBO 135.00.00.000 Torque Wrench, 1 pc. Set of Interchangeable Parts: — Jaw 60–102, 1 pc. — Jaw 102–144, 1 pc. — Jaw 144–178, 1 pc. — Jaw 176–194, 1 pc. — Jaw 324–351, 1 pc. — Jaw 426–451, 1 pc. Spare Parts, Tools and Accessories (SPTA) Kit: — Bushing, 2 pcs. — Die, 4 pcs. — Bolt, 8 pcs. — Spring, 2 pcs. |
