Telescopic Mast A50M.01.00.000
About the product
The mast is telescopic, welded, two-section and inclined.
The mast is designed for use on A50M-type workover and well servicing units (UPA-60A 60/80).
Technical specifications
| Code | Rated Load Capacity, t | Overall Dimensions, mm | Weight, kg |
|---|---|---|---|
| Mast A50M.01.00.000 | 60 |
Upper section – 11110×900×1200 Lower section – 10600×1112×1802 |
2500 |
Mast Assembly Includes:
| 1 | A50MP.01.01.000 | Lower Mast Section |
| 2 | A50MP.01.02.000 | Upper Mast Section |
| 3 | A50MP.01.03.000-01 | Mast Crown Block |
| 4 | A50MP.01.03.000-02 | Mast Crown Block |
| 5 | A50M.01.05.000 | Mast Locking Device |
| 6 | A50M.01.06.000 | Mast Ladder |
| 7 | A50M.01.06.000-01 | Mast Ladder |
| 8 | A50MP.01.03.000 | Mast Crown Block |
| 9 | A50M.01.07.000 | Guy Lines |
| 10 | A50M.01.08.000 | Upper Mast Section Lift Limiter |
| 11 | A50M.01.09.000 | Traveling Block Limiter |
| 12 | A50M.01.10.000 | Crown Block Platform |
| 13 | A50M.01.11.000 | Safety Wire Rope |
| 14 | A50M.01.12.000 | Safety Wire Rope |
| 15 | A50M.01.13.000 | Wire Rope Guide |
| 16 | A50M.01.15.000 | Upper Section Ladder |
| 17 | A50M.01.16.000 | Nameplate Mounting Assembly |
| 18 | A50M.01.18.000 | Auxiliary Suspension Assembly |
| 19 | A50MA.01.04.000 | Upper Mast Section Lifting Device |
