Brake Pneumatic Cylinder A50M.02.03.240
About the product
The brake cylinder is a component of the braking system of a workover and well servicing unit.
The brake cylinder is manufactured in full compliance with drawing A50M.02.03.240.
The manufacturer reserves the right to modify the design provided that such modifications do not impair the operating characteristics of the product.
Polymer bushings requiring no additional lubrication of the friction pair are used in the design of this batch of products.
Technical specifications
| Item No. | Part No. | Description | Qty. |
|---|---|---|---|
| 1 | A50M.02.03.140 | Piston Assembly | 1 |
| 2 | A50M.02.03.021 | Cylinder Sleeve | 1 |
| 3 | A50M.02.03.019 | Seal | 1 |
| 4 | A50M.02.03.022 | Buffer | 1 |
| 5 | A50M.02.03.023 | Spring | 1 |
| 6 | A50M.02.03.013 | Bushing | 1 |
