RK-01 Cable Roller with Cutter
About the product
The RK-01 Cable Roller with Cutter is designed for lowering and lifting power cables for submersible pumps in oil wells
Technical specifications
| Parameter | Value |
|---|---|
|
Parameter Name |
Value |
|
Shear pin breaking force, kgf |
1000 ± 50 |
|
Load on one power cable leg, kgf |
500 ± 25 |
|
Breaking strength of the power cable, kgf |
3000 ± 150 |
|
Maximum load on the roller, kgf |
6000 |
|
Operating temperature, °C |
-40… +45 |
|
Overall dimensions of the RK-01 cable roller, mm Roller diameter Height Width Length |
880 900 180 900 |
|
Weight, kg |
58 |
Description
The cable roller is designed for lowering and retrieving the power cable of electric submersible pumps (ESP) in oil wells. Its design provides automatic cutting of the cable in emergency situations, such as tubing string failure ("tubing drop") during the running or pulling of the ESP.
Climatic version: UHL. Installation category I in accordance with GOST 15150-69.
