Hook Block A50M.18.00.000K
About the product
The A50M.18.00.000K crown block and hook is a combined lifting device that integrates the functions of a traveling block and a hook. It is designed for use in drilling rigs during drilling and workover operations on oil and gas wells.
Technical specifications
| Name |
Used in Units |
Load Capacity |
Dimensions |
Weight |
|---|---|---|---|---|
| A50M.18.00.000K Hook Block | UPA60/80, A60/80 | 80 t | ≈ 1811×652×511 mm | ≈ 810 kg |
The A50M.18.00.000K Hook Block is used as part of drilling equipment for the vertical lifting of drill pipe strings and other auxiliary tools. It is equipped with a swivel hook that allows the suspended equipment to rotate freely, reducing the load on the connecting assemblies.
| Item No. | Part Number | Name | Qty |
|---|---|---|---|
| 1 | A50M.18.01.000 | Cup Housing | 1 |
| 2 | A50M.18.02.000 | Cup Housing | 1 |
| 3 | A50M.18.03.000 | Half Clamp | 1 |
| 4 | A50M.18.04.000 | Protective Cover | 2 |
| 5 | A50M1.18.02.000K | Main Stem | 1 |
| 6 | A50M1.18.01.000K | Hook Assembly | 1 |
| 7 | A50M.18.00.005 | Latch | 1 |
| 8 | A50M.18.00.006 | Pin | 2 |
| 9 | A50M.18.00.012 | Bushing | 2 |
| 10 | A50M.18.00.013 | Handle | 1 |
| 11 | A50M.18.00.015I | Crosshead | 1 |
| 12 | A50M.18.00.016 | Key | 1 |
| 13 | A50M.18.00.018 | Roller | 3 |
| 14 | A50M.18.00.019 | Half Clamp | 1 |
| 15 | A50M.18.00.021 | Pin | 1 |
| 16 | A50M.18.00.022 | Side Plate | 2 |
| 17 | A50M.18.00.023 | Latch | 2 |
| 18 | A50M.18.00.024 | Axle | 1 |
| 19 | A50M.18.00.027 | Spring | 1 |
| 20 | A50M1.18.00.001K | Shackle | 1 |
| 21 | 4KORO.20.03.006 | Axle Retainer | 1 |
| 22 | A50M1.18.00.002K | Hinge Pin | 1 |
| 23 | A50M1.18.00.025K | Dowel Pin | 1 |
| 24 | 8244 | Bearing (GOST 7872-89) | 1 |
| 25 | 224 | Bearing (GOST 8338-75) | 6 |
