Outrigger A50M.49.06.000-09
About the product
The rear outrigger is a double-acting hydraulic cylinder designed to level and stabilize the A50M unit during operation.
Technical specifications
| Parameter | Value |
|---|---|
| Piston Diameter, mm | 160 |
| Rod Diameter, mm | 140 |
| Piston Stroke, mm | 350 |
| Maximum Pressure, MPa | 10 |
| Weight, kg | 155.3 |
